Black Weather-Resistant High-Density Polyethylene (HDPE) Insulation Compound

Black Weather-Resistant High-Density Polyethylene Insulation Compound

Black Weather-Resistant High-Density Polyethylene (HDPE) Insulation Compound is a cable insulation material based on polyethylene (PE) resin, modified with additives such as antioxidants and stabilizers. Its core function is to provide electrical insulation protection for wires and cables while delivering excellent mechanical and chemical properties. This insulation material is suitable for the insulation layer of communication cables, optical cables, submarine cables, local telephone cables, coaxial cables, control cables, and power cables.

Black Weather-Resistant High-Density Polyethylene Insulation Compound List

Model	Unit	HDPE-5E
Item	/	Typical
Density	g/cm3	0.94
Melt Flow Index (MFI) (190°C, 2.16 kg)	g/10 min	0.8
Tensile Strength	MPa	25.0
Elongation at Break	%	850
Air Oven Aging	℃×h	100×240
Tensile Strength Change Rate	%	-4
Elongation at Break Change Rate	%	-8
Heat Deflection (90°C, 4h)	%	/
Thermal Shock	℃×h	130×1
Test Result	/	No cracking
Thermal Shrinkage Test	℃×h	/
Shrinkage Rate	%	/
Low-temperature Performance Test	℃	-25
Low-temperature Impact Brittleness Temperature	℃	-76
Ozone Resistance Test	/	No cracking
Environmental Stress Cracking Resistance	h	≥500
Thermal Stress Cracking Resistance	h	≥96
Artificial Weathering	h	1008 h, pass
Volume Resistivity at 20°C	Ω·cm	4.0×1016
Dielectric Strength at 20°C	kV/mm	29
Environmental Protection Requirements	/	Conforms to EU RoHS Directive (2011/65/EU) and REACH Regulation (EC 1907/2006) Substances of Very High Concern (SVHC) provisions.

Black Weather-Resistant High-Density Polyethylene Insulation Compound Application

Black Weather-Resistant High-Density Polyethylene (HDPE) Insulation Compound exhibits excellent mechanical and chemical properties and is suitable for the insulation layer of communication cables, optical cables, submarine cables, local telephone cables, coaxial cables, control cables, and power cables. Details as follows:
Black Weather-Resistant HDPE Insulation Compound
Features: Weather resistance, superior insulation properties; smooth, round extruded surfaces with excellent finish.
