Model FD2No. of Wires 2Inlet Wire Diameter 2*φ1.0-1.6 mmOutlet Wire Diameter 2*φ0.12-0.4 mmLine Speed (Max.) 2000 m/minNo. of Dies (Max.) 24Motor Power 18.5-22 KWTake-up Power 4.4-7.4 KWConductor Type Copper, aluminum, and related alloys wires.Drive System Frequency converter
FD2 Dual-line Fine Aluminum Wire Drawing Machine
FD2 dual-line fine aluminum wire drawing machine is a specialized equipment line used to process medium aluminum wire (usually with a diameter of Φ1.0-1.6 mm) into fine aluminum wires (Φ0.12-0.4 mm) through multiple passes of stretching.
FD2 Dual-line Fine Aluminum Wire Drawing Machine Datasheet
| Item/Model |
FD2S |
FD2L |
| No. of Wires |
2 |
2 |
| Inlet Wire Dia. |
2*φ1.0-1.2 mm |
2*φ1.0-1.6 mm |
| Outlet Wire Dia. |
2*φ0.12-0.32 mm |
2*φ0.12-0.4 mm |
| Line Speed (Max.) |
2000 m/min |
2000 m/min |
| No. of Dies (Max.) |
24 |
24 |
| Main Motor |
18.5 KW |
22 KW |
| Take-up Motor |
2*2.2 KW |
2*3.7 KW |
| Correction System |
Automatic control |
Automatic control |
| Brake |
Pneumatic brake |
Pneumatic brake |
| Take-up Capacity |
2*25 kg |
2*50 kg |
| Take-up Spool |
φ250 mm |
φ300 mm |
FD2 Dual-line Fine Aluminum Wire Drawing Machine Application
FD2 dual-line fine aluminum wire drawing machine is a specialized equipment line used to process medium aluminum wire (usually with a diameter of Φ1.0-1.6 mm) into fine aluminum wires (Φ0.12-0.4 mm) through multiple passes of stretching.
