FD2A Dual-line Fine Copper Wire Drawing Machine Line with Continuous Annealing

FD2A Dual-line Fine Copper Wire Drawing Machine Line with Continuous Annealing

FD2A dual-line fine copper wire drawing machine line with continuous annealing is a specialized equipment line used to process medium copper wire (usually with a diameter of Φ0.6-1.6 mm) into fine copper wires (Φ0.12-0.5 mm) through multiple passes of stretching.

Characteristic

1. It can draw 2 copper wires at the same time, which has the advantages of high speed, energy saving, and saving space and manpower;
2. The wire winding adopts dual frequency conversion and dual motor control, ensuring stable wire drawing;
3. The tension is independently controlled and not easily broken;
4. There are two options for closing the line: closing on two separate reels or closing on one reel.

FD2A Dual-line Fine Copper Wire Drawing Machine Line with Continuous Annealing Datasheet

Item/Model	FD2AS	FD2AL
No. of Wires	2	2
Inlet Wire Dia.	2*φ0.6-1.2 mm	2*φ1.0-1.6 mm
Outlet Wire Dia.	2*φ0.12-0.35 mm	2*φ0.19-0.5 mm
Line Speed (Max.)	2000 m/min	2000 m/min
No. of Dies (Max.)	24	24
Main Motor	22 KW	30 KW
Take-up Motor	2*2.2 KW	2*3.7 KW
Annealing Motor	42 KVA	56 KVA
Correction System	Automatic control	Automatic control
Annealing Method	DC three-section annealing	DC three-section annealing
Brake	Pneumatic brake	Pneumatic brake
Take-up Capacity	2*25 kg	2*50 kg
Take-up Spool	φ250 mm	φ300 mm

FD2A Dual-line Fine Copper Wire Drawing Machine Line with Continuous Annealing Application

FD2A dual-line fine copper wire drawing machine line with continuous annealing is a specialized equipment line used to process medium copper wire (usually with a diameter of Φ0.6-1.6 mm) into fine copper wires (Φ0.12-0.5 mm) through multiple passes of stretching.
